型號Type | TG-500 | TG-600 | TG-800 | TG-1000 | TG-1200 | TG-1500 |
轉鼓直徑 Drum diameter | 500 | 600 | 800 | 1000 | 1200 | 1500 |
轉鼓高度 Drum height | 260 | 300 | 340 | 380 | 480 | 600 |
主軸轉速(r/min) Drum speed | 1000 | 1000 | 910 | 900 | 750 | 750 |
電機功率(Kw) Motor power | 1.1 | 2.2 | 4 | 5.5 | 7.5 | 10 |
最大容量(Kg) Max.capacity | 25 | 45 | 80 | 130 | 220 | 500 |
外形尺寸 Overall dimensions | 1000x1000 x650 | 1250x1250 x700 | 1500x1500 x800 | 1800x1800 x900 | 2000x2000 x1000 | 2550x1950 x1400 |
